Application scope:

· Mainly suitable to steel wire heat treatment plating copper, especially suitable to high pressure rubber pipe steel wire, steel curtain wire, cutting steel wire and conveyor belt used steel wire.

Technology process:

Release wire→degrease groove→fire heating furnace→AQ groove→water cooling groove→electroplating alkali washing groove→water flow washing groove→hydrochloric acid scouring groove→water flow washing groove→copper plating groove→water flow washing groove→galvanization groove→water flow washing groove→heat water washing groove→MF→water cooling groove→phosphoric acid washing groove→water flow washing groove→soap soaking groove→wire retrieve machine

(Note: the above steps only for reference, we can modify it according to different requirements from customers)

Technical parameters:

· Material: high carbon steel wire, carbon content 0.7~0.9%

· φ0.7～φ2.20mm；Steel wire diameter:φ0.7～φ2.20mm;

· DV：50～85mm/min  Running speed: DV: 50～85mm/min

· 42/48/56/60； Steel wire quantity: 42/48/56/60

· 4～8g/kg； Plated layer weight: 4~8g/kg;

· Output: according to customer requirements.
